1995 Corvette ZR-1

1995 Corvette Common Issues

The following list of common issues is intended for individual reference only, and may not reflect the specific issues of every 1995 Corvette.  While the intent of this page is to identify the common issues pertaining to the 1995 Corvette, it is not an all-inclusive list and should be used for reference only.

Read more: 1995 Corvette Research Center

1995 Corvette Recalls, Technical Service Bulletins, & Maintenance Schedule

The information contained on this page is for reference only.  The time and mileage intervals for each of the maintenance items included on this page were established by General Motors with the introduction of the 1995 Chevy Corvette.  Please note that the original service intervals may not reflect the standard service intervals used in current automobile engines.

Read more: 1995 Corvette Recalls, Technical Service Bulletins, & Maintenance Schedule.




1995 Corvette Common Issues

The following list of common issues is intended for individual reference only, and may not reflect the specific issues of every 1995 Corvette. This information comes from a variety of sources including the NHTSA Defects Reports pages. While the intent of this page is to identify the common issues pertaining to the 1995 Corvette, it is not an all-inclusive list and should be used for reference only.

Mechanical Issues

Engine

The Opti-Spark Ignition System has been known to fail on late model C4 Corvettes (those equipped with PFI V8 engines).

Failure of the Opti-Spark Ignition System may prevent the vehicle from starting.

Failure of the Ignition Lock Cylinder occurs, though infrequently, preventing the vehicle from starting.

The LT1 engine is prone to engine oil leaks, most especially around the front and rear of the intake manifold. The manifold was sealed at the ends with RTV rather than gasket material and tended to leak even straight from the factory. Other common areas to check for oil leaks on the engine include: the timing chain cover, the valve covers, the waterpump drive seal, the oil pan, and the front and rear main bearing seals.

The LT1 engine often exhibits a rough idle at start-up, especially after the car has been sitting for an extended period of time. The most probable cause of the idling issue is fouled injectors. In many instances, adding a fuel stabilizer and/or fuel injection cleaner to the fuel tank helps resolve this issue.

Transmission

A transmission leak may occur from the pump body on 4L60-E transmissions due to the pump bushing walking out of the valve body.

It should be noted the ZF6 transmission is somewhat noisy (particularly in neutral with the clutch out)

The transmission is controlled by an electronic control unit. In some instances, this unit is known to fail, causing erratic transmission shifting problems resulting in drivability issues.

Radiator

It is quite common for road debris and trash to get sucked up between the radiator and the A/C condensor, thereby blocking air flow and causing the engine to overheat. This area should be inspected and cleaned out at regular intervals.
Check the underside of the radiator for signs of leaking coolant, the side tanks on the factory radiator are constructed of plastic and may be cracked and leaking on a higher mileage car.

Air Conditioning

Unfortunately, all 1995 Corvettes are subject to one of two A/C problems:

First, failure to be able to raise or lower cabin temperature by pushing on the temperature up/down control buttons on the dash are usually due to a failed A/C Controller Module.

Second, air conditioning blows on the floor or through the defrost vents only but not through the dash vents. These are indications of a bad A/C Program Module.

Exterior Issues

Weather Stripping

The weather stripping on all late model C4 Corvettes is not very durable and is a very costly repair. The weather stripping is known to crack, rip, and tear. The weather stripping at the base of the windshield and at the coupe hatchback glass is generally the first, most common portion to fail.

Front Air Dam Spoiler

Because of the low front-end clearance on the Corvette, the front air dam spoiler tends to get damaged even as the result of normal vehicle operation. The front air dam spoiler tends to get scraped up and damaged very easily. Replacement spoilers are available both through General Motors and a variety of aftermarket suppliers.

Power Antenna Mast

The power antenna mast is known to fail for a number of reasons including: improper (or lack of) lubrication, physical damage to the antenna itself, damage to the drive mechanism that raises/lowers the mast.

Interior Issues

Driver & Passenger Seats

The first area that most commonly fails are the side bolsters and the seat bottoms, particularly on the driver’s side. The leather on the factory seats is fairly thin and not very durable. Factory original seat cover replacements are no longer available from GM.

The plastic bezel around the seat back release in the back of each headrest are prone to breakage.

Steering Wheel

Steering wheels may exhibit vertical play. If the steering wheel exhibits more than just minimal up and down movement, then the Corvette may have been damaged as the result of prior vehicle operators using the steering wheel as a means of pulling themselves out of the vehicle. The vertical motion indicates that the steering column mounting bolts are probably damaged. While this issue is repairable, it is a very time consuming and expensive repair.

Center Console Cover

The center console lid is commonly known to crack, which is an issue with all C4 Corvettes.

Window Motor

The window motor is commonly known to failure, resulting in inconsistent window operation or the inability to open/close either the driver or passenger windows.

Other Issues

Owners should not be concerned if minor, though visible evidence of overspray (or even blotches) of paint under the hood, particularly in the area around the hood latch pins and receptacles. This was very common on factory production cars of this era and should be expected. In fact, owners should be more concerned if they do NOT see any overspray or spray paint in this area.
