1986 COrvette

1986 Corvette Performance & Specifications

Powertrain, Steering, Brakes, Dimensions, & Suspension

Last updated:

For those that lived through that era, 1986 probably resonates as one of the most innovative and exciting years of the entire decade.  It was the year that the Human Genome Project began, a study that would help scientists understand and map the genetic structure of the human body.

Read More: 1986 Chevrolet Corvette Research Center

1986 Corvette Specifications

1986 Corvette Main Specs

MODEL: 1985 Chevrolet Corvette
BODY STYLE: Two-door Coupe/Hatchback, front engine, rear wheel drive
MANUFACTURING LOCATION: Bowling Green, Kentucky
CONSTRUCTION: Fiberglass body, unibody construction with partial, front frame including both steel and stainless steel components.
VEHICLE NUMBERS (VIN):
1G1YY0789G5100001 THRU 1G1YY0789G5127794 (coupe)
1G1YY6789G5900001 THRU 1G1YY6789G5907315 (convertible)
VIN SUFFIX: DKF: 350 CUBIC INCH, 230 HP, IRON HEADS, AUTOMATIC, OIL COOLER
DKC: 350 CUBIC INCH, 230 HP, IRON HEADS, AUTOMATIC
DKH: 350 CUBIC INCH, 230 HP, IRON HEADS, AUTOMATIC, EXPORT
DKD: 350 CUBIC INCH, 230 HP, IRON HEADS, MANUAL, OIL COOLER
DKB: 350 CUBIC INCH, 230 HP, IRON HEADS, MANUAL
ZJS: 350 CUBIC INCH, 235 HP, ALUMINUM HEADS, AUTO, OIL COOLER
ZJH: 350 CUBIC INCH, 235 HP, ALUMINUM HEADS, AUTOMATIC
ZKD: 350 CUBIC INCH, 235 HP, ALUMINUM HEADS, AUTOMATIC, EXPORT
ZJW: 350 CUBIC INCH, 235 HP, ALUMINUM HEADS, MANUAL, OIL COOLER
ZKA: 350 CUBIC INCH, 235 HPR, ALUMINUM HEADS, MANUAL
ENGINE BLOCK NUMBER: 14088548: ALL
HEAD NUMBER: 462624: IRON HEADS, 14101128: ALUMINUM HEADS

1986 Corvette Powertrain Specifications

Engine: L98 5.7 OHV 350 V-8.
Cylinders: V8
Block Material:
Cast Iron Alloy
Displacement: 5.7 Litre/350 Cubic Inches
Bore & Stroke: 4.00 x 3.48 inches
Valvetrain: OHV, 2 valves per cyl.
Cylinder Head Material: Cast Iron Alloy
Cylinder Block Deck Height: 9.025 Inches
Compression Ratio: 9.00:1
Horsepower: 230 HP @ 4,000 RPM
Torque: 330 lb-ft @ 3,200 rpm
Fuel Delivery: Tuned-Port Fuel Injection
Fuel Capacity: 20.0 Gallons
Oil Capacity: 4.0 Quarts (Without Filter)
Total Dressed Engine Weight (Dry): 585.7 lbs
Transmission: 4+3 Speed Manual (4 Speed Manual with Overdrive in 3rd and 4th), 4-Speed Automatic
Standard Axle Ratio: 2.73:1 (Automatic), 3.07:1 (Manual)

1986 Corvette Wheels, Suspension & Brakes

Suspension (Coupe)

Front Suspension Single fiberglass composite mono-leaf transverse spring with unequal-length aluminum control arms and stabilizer bar.
Rear Suspension Fully independent five-link system with transverse fiberglass single-leaf springs, aluminum upper/lower trailing links and strut-rod tie-rod assembly

Wheels & Tires (Coupe)

Front Tires P255 / 50VR16
Rear Tires P255 / 50VR16
Front Wheels Wheels: 16 x 8
Front Wheels Wheels: 16 x 8

Brakes (Coupe)

Front Brakes Power Disc Brakes
Rear Brakes Power Disc Brakes

1986 Corvette

1986 Corvette Exterior Dimensions

Coupe Dimensions

1985 Corvette Dimensions

Exterior Dimensions (Coupe) Interior Dimensions (Coupe)
Wheelbase: 96.2 Inches Headroom: N/A
Overall Length: 176.5 Inches Shoulder Room: N/A
Total Body Width: 71.0 Inches Hip Room: N/A
Overall Height: 46.7 Inches Leg Room: N/A
Front Track Width: 59.6 Inches
Rear Track Width: 60.4 Inches
Min. Ground Clearance 4.5 Inches

Convertible Dimensions

Exterior Dimensions (Coupe) Interior Dimensions (Coupe)
Wheelbase: 96.2 Inches Headroom: N/A
Overall Length: 176.5 Inches Shoulder Room: N/A
Total Body Width: 71.0 Inches Hip Room: N/A
Overall Height: 46.7 Inches Leg Room: N/A
Front Track Width: 59.6 Inches
Rear Track Width: 60.4 Inches
Min. Ground Clearance 4.5 Inches

Capacities

Capacities
Passenger Capacity 2 – Driver & Passenger
Curb Weight (lbs) 3,101 (Coupe), 3,279 (Convertible)
Interior Passenger Volume (cu. ft) 8.4
Interior Trunk Volume (cu. ft) 24 (approximately)
Fuel Capacity (gallons): 20.0
Coolant capacity without heater (qts.) 21.6
Battery: 12 Volt, 3,500 Watts
Generator Output: 14-22 Amps

1986 Corvette


1986 Corvette Performance Results

Performance Results
0-30 MPH: 2.4 Seconds
0-60 MPH: 5.8 Seconds
0-100 MPH: 14.4 Seconds @ 96.0 mph
QUARTER MILE: N/A
TOP SPEED: 150 mph
