1997 C5 Corvette RPO Codes, Options Codes & Order Guide
If you are looking to decode your 1997 Corvette RPO’s (option codes), then check out the table below. We have included an easy to use search feature too if you are looking for a specific code just type it into the search field to navigate to it quickly. We have also included the full 1997 Corvette Order Guide further down in the post.
1997 Corvette RPO Codes
| Code | Description |
|---|---|
| AAB | Memory, Driver Convenience Package |
| AG2 | Power Seat Adjuster, Passenger, 6-Way |
| AK5 | Inflatable Restraint System, Front Seat, Driver and Passenger |
| AQ9 | Reclining Seat, Driver and Passenger (Sport Seat) |
| AR9 | Reclining Seat, Driver and Passenger, European Style (Base Seat) |
| AX4 | Conversion, Seat Belt, European |
| BAG | Loose Parts Bag, Export |
| B34 | Covering Front Floor Mats, Carpeted Insert |
| B4H | Modification, Noise Control, Export |
| B84 | Molding, Body Side, Exterior |
| CC3 | Roof Panel, Removable (Transparent) |
| CF7 | Roof Panel, Removable (Nontransparent) |
| CJ2 | HVAC System, Air Conditioning, Automatic Temperature Control (Dual Zone) |
| CU7 | Country Code, Kuwait |
| CU8 | Country Code, Saudi Arabia |
| CV5 | Country Code, Japan |
| CW2 | Country Code, Gulf States |
| C2L | Roof Package, Dual Removable (consists of CC3 and CF7) |
| C60 | HVAC System, Air Conditioning, Manual Control |
| DL8 | Mirrors, Outside, LH/RH Remote Control Electric, Heated |
| D42 | Shade, Rear Compartment Security (includes cargo net) |
| EXP | Export, N.A.E.S. |
| FE1 | Suspension System, Soft Ride |
| FE3 | Suspension System, Sport |
| FE9 | Certification, Federal Emission |
| F45 | Chassis, Selective Real Time Damping |
| GU2 | Axle, Rear, 2.73 Ratio |
| GU6 | Axle, Rear, 3.42 Ratio |
| G90 | Axle, Rear, 3.15 Ratio |
| G92 | Axle, Rear, Performance Ratio |
| IL3 | Trim, Interior Design (L3) (Base w/ AQ9) |
| IP3 | Trim, Interior Design (P3) (Base w/ AR9) |
| JL9 | Brake System, Power, Front & Rear Disc, Antilock, 4-Wheel |
| K05 | Heater, Engine Block (Canadian) |
| K29 | Module, Powertrain Control (Non-OBD II, Unleaded) |
| K63 | Generator, 110 Amp |
| LS1 | Engine, Gas, 8-Cylinder, 5.7L, SFI, Aluminum (VIN G) |
| MAE | Marketing Area, Europe |
| MAU | Marketing Area, Unregulated |
| MM6 | Transmission, Manual 6-Speed, Borg Warner |
| M30 | Transmission, Automatic 4-Speed, 4L60-E, Electronic |
| NB6 | Emission System, California, Tier 1 |
| NF2 | Emission System, Federal, Tier 1 |
| NK4 | Steering Wheel, Sport Leather |
| NM8 | Leaded Fuel System, Compatible |
| NV7 | Steering, Power, Variable Effort |
| N73 | Wheel, Custom Sport, Magnesium, Export |
| QD4 | Wheel, 17.0 x 8.5" Front and 18.0 x 9.5" Rear, Aluminum, Styled |
| T84 | Headlamps, RH Rule of Road |
| T85 | Headlamps, LH Rule of Road |
| T89 | Lamps, Tail, Stop & Turn, Export |
| T90 | Lamps, Signaling & Marker, Front |
| T93 | Lamps, Tail, Stop & Turn, Special |
| T96 | Lamps, Fog |
| UD4 | Over Speed Warning, 120 km/h |
| UK1 | Radio Frequencies, Japanese |
| UL0 | Radio, AM/FM Stereo, Seek/Scan, Auto Reverse Music Search Cassette, Auto Tone, Clock, Electronically Tuned Receiver (ETR) |
| UL2 | Radio Frequencies, European |
| UN0 | Radio, AM/FM Stereo, Seek/Scan, Compact Disc, Auto Tone, Clock, Electronically Tuned Receiver (ETR) |
| UV7 | Antenna, Windshield, Rear Lift Window, Radio |
| UZ6 | Speaker System, 6, Quad Front Door Mounted, Dual Quarter Mounted |
| U1S | Changer, Remote Compact Disc |
| U19 | Instrument Cluster, Metric (Canadian, Export) |
| U52 | Instument Cluster, Electronic |
| VB1 | Label, Shipping, Japan |
| VC5 | Label, Shipping, Except US/Japan |
| VD1 | Provision Options, Europe |
| VE1 | Provision Options, Japan |
| VE3 | Label, Battery Disposal |
| VG1 | Protector, Transit Coating, Underhood |
| VG9 | Protector, Transit Coating, Exterior Body |
| VH5 | Plate, Vehicle Identification |
| VL4 | License Plate Mounting Package, Front |
| V49 | License Plate Frame (front) |
| V73 | Vehicle Statement, US/Canada |
| V76 | Tow Hooks |
| V78 | Vehicle Statement Delete |
| V87 | Vehicle Statement, Gulf States |
| XGG | Tire, Front, P245/45ZR17, BW TL SBR HW4, EMT |
| XMC | Tire, Front, P245/45ZR17, BW TL SBR HW4 |
| YGH | Tire, Rear, P275/40ZR18, BW TL SBR HW4, EMT |
| YME | Tire, Rear, P275/40ZR18, BW TL SBR HW4 |
| Z49 | Modifications, Canadian, Mandatory Base Equipment |
| Z51 | Performance Package, Handling |
| 10U | Primary Color, Exterior, Arctic White (#10) |
| 13U | Primary Color, Exterior, Sebring Silver (#13) |
| 19I | Interior Trim, Black |
| 193 | Trim Combination, Leather, Black |
| 23U | Primary Color, Exterior, Nassau Blue (#23) |
| 41U | Primary Color, Exterior, Black (#41) |
| 53U | Primary Color, Exterior, Lt Carmine Red Metallic (#53) |
| 70U | Primary Color, Exterior, Torch Red (#70) |
| 87U | Primary Color, Exterior, Fairway Green (#87) |
| 92I | Interior Trim, Lt Gray |
| 923 | Trim Combination, Leather, Lt Gray |
| 94I | Interior Trim, Firethorn Red |
| 943 | Trim Combination, Leather, Firethorn Red |
| Code | Description |
1997 Corvette Order Guide
Coming Soon
